How deep should a deck footing be

By code, the bottom of a footing must be at least 12 inches deep and below the local frostline—whichever is deeper—and bear on stable, undisturbed soil that is free of organic matter.

How deep and wide do deck footings need to be?

FOOTINGS: – Poured concrete footings should be a minimum of 8” wider than the posts (4×4 post – 12” min. width, 6×6 post – 14” min. width), a two level deck or deck with roof – 24”x24”. – The bottom of the footings must be a minimum of 36” below finish grade level.

What is the code for deck footings?

Footings need to be at least 12 inches below settled soil to prevent lateral movement. In addition, they need to be dug below the frost line, which varies according to climactic zone.

How deep do holes have to be for deck posts?

Dig the holes six inches deeper than the required frost line depth for your area, and slightly wider than the concrete footer tubes you’ll be using. A power auger can make this step easier and faster.

How many footings do I need for a 12x12 deck?

For an attached 12 x 12′ deck, you’ll need at least 3 footings, plus at least 2 more if you’re planning on building stairs with it. If your deck will be a different size, it’s easy to figure out how many you’ll need.

How many footings do I need for a 12x16 deck?

A standard deck will need four footings parallel to the house, but they will need to be temporarily braced by 6 inch-by-6 inch posts. Using doubled boards, you will then need to build beams on the top row of the posts to frame the edges of the deck. These must be topped with adjustable post caps.

Do I need footings for a deck?

Large decks that are attached to the house should always have footings because they act to spread the heavy load of the deck from the surface of a support post over a large surface of the soil so the ground can adequately support it. … The footings ensure that the deck will not fall, tip or rot away after a few years.

How big should my footing be?

Depth, Width, and Thickness of Footings Footings should extend to a minimum depth of 12 inches below previously undisturbed soil. Footings also must extend at least 12 inches below the frost line (the depth to which the ground freezes in winter) or must be frost-protected.

Can I use deck pier blocks instead of footings?

Pier blocks can be used instead of footings for a ground-level deck not requiring permits. … Any decks higher than 24” require concrete piles 10” in diameter and 48” below grade. These footing size requirements are to ensure enough soil bearing to prevent the joist from sinking in the ground.

Should you use 4x4 or 6x6 deck posts?

While there may be a handful of circumstances that only require the minimum 4×4 deck post, you will more than likely want to choose a 6×6 post for the deck. It provides more stability for larger decks, the ability to hold a heavier load, and more room for notching.

Article first time published on

How many footings do I need for a floating deck?

For an 8×10′ freestanding deck, you’ll need six footings. Unless you have access to a power auger, that’s a lot of digging. After digging each hole, you will need to install tube forms into each. Each tube form then needs to be filled with one 60 lb.

Can I use 4x4 posts for my deck?

In the past, many decks were built with 4×4 support posts (also called structural posts). But these can bow seriously, even if a deck is only 3 feet off the ground. For that reason, we strongly recommend that you use 6x6s instead, even if your building department does not demand them.

Can I use 2x6 for deck joists?

2×6 joists should only be used on ground-level decks that do not require, and will not provide for, any guards. … Most decks use 16″ on center spacing for joists. Most decking is not strong enough to support longer spans than 16″.

How far apart should deck joists be?

Step 4: Make Sure Your Joists Are Spaced Correctly Deck joist spacing should never exceed 16″ on center (with the exception of MAX deck boards, which allow for maximum 24″ on center). For a more rigid feel, 12″ or less may be preferred.

Can I use 2x6 for deck frame?

Or are 2x6s to small for deck joists? You can use 2×6 as deck joists if the deck is low enough to the ground as not to require guard railing. When using S-P-F 2×6 deck joists, the span must not be greater than 9’0″ (2.73m) with joists at 16″ o.c. (400mm), and 9’10” (3.01m)with spacing at 12″ (300mm).

Do ground level decks need footings?

If you want to expand your outdoor living space, a ground level deck might be your best option. Since it’s not connected to a house, it can go anywhere in your yard and doesn’t require deep footings. Because it rises just inches above ground, it doesn’t need stairs or railings.

How many posts do I need for a 12 foot deck?

The shorter sides—in this case, the 8-foot side—will have 4-feet of distance between deck posts. The larger 12-foot side will have a post spacing of 6 feet at a minimum code requirement. That makes a total of eight posts that need to be installed on this average size deck.

Can I build a deck without digging holes?

Yes. It’s possible to build a deck without digging holes. This type of deck is called a floating deck, and it sits right on top of the ground without any posts or support areas that you’d dig down into the ground [to secure].

Do deck blocks sink?

The deck blocks can sink if the soil under them erodes for some reason or the weight is unevenly distributed. That’s why it’s a good idea to use more than less. … Especially in loose soils or wet conditions which requires more weight distribution.

How far apart should deck blocks be?

Space the deck blocks at 4′ to 6′ intervals to offer the frame good support.

What is the minimum depth of footing?

The minimum depth of footing in sloping ground with the rock, the horizontal distance shall be at least 600 mm or 2 feet from the lower edge of the footing. In case of sloping ground with normal soil, the horizontal distance shall be 900 mm or 3 feet from the lower edge of footing.

How thick should footings be?

Eight inches is the minimum thickness for a footing. Ten inches is better and twelve inches is highly desirable. The depth of the footing in the ground depends on: the local frost depth.

Do you put gravel under footings?

You do need gravel under a concrete slab, footing, or patio. Gravel provides a solid foundation for your concrete as it can be compacted. It also improves drainage, preventing water from pooling beneath the concrete.

Should deck joists be 2x6 or 2x8?

That’s a model deck code which includes joist span tables. If there is to be a railing, you need the joists to be at least 2x8s. 2x6s don’t have the depth needed to resist the leverage that can be placed on a railing post bolted to them.

Should I set my deck posts in concrete?

A deck post should always be placed on top of footing, not inside concrete because it can break. … Concrete tends to absorb moisture and wood expands when it gets wet, so these two factors combined will result in the wood breaking the concrete.

Should you notch deck posts?

Say “No” to notching pressure-treated deck posts. We want you to build an outdoor railing system that you, your family and guests can enjoy without worrying about safety issues. In order to do so, you need to know this building shortcut is not advisable, and we recommend avoiding it at all costs.

How many posts do I need for a 10x10 deck?

A freestanding 10′ x10′ deck needs 4 posts, supporting two pairs of 2-ply non-incised 2×8 beam, upgrading the beam to 3-ply using incised wood.

How much weight can a pressure treated 4x4 hold vertically?

4×4 can hold up to 4,000 pounds when laying horizontally with the right support. Vertically, a 4×4 should support 4300 pounds but can hold significantly more. The amount of weight that a 4×4 can hold depends on several factors like wood grade, species, and load type.

What is Max distance between deck posts?

Ideal deck post spacing is 8 feet or less. The distance between deck support posts depends on the type of wood species used and the size of the joist and beam. There is no minimum span, and maximum spans can reach up to 15′.

What is a deck footing?

Footings are a very important component of deck construction because they provide the solid foundation that will support your deck. Your deck’s design will determine how live and dead loads are transferred from different sections of the deck to concentrated points of contact with the ground.
